Introduction

Before I start, I should say the APEX_JSON PL/SQL API (available since APEX 5.0) is one of the most useful APIs the APEX development team have provided. I have used APEX_JSON to generate and parse JSON on countless occasions. It served me well through the 11g database years. Since the last of my clients moved off 11g, however, I have managed to wean myself off APEX_JSON (mostly). The main reason being performance. I still think APEX_JSON is easier to understand and is more developer friendly. It's just a lot slower than the native JSON functionality available since 12c.

In this blog post, I'll demonstrate exactly how much faster native database JSON functionality is. Both in generating JSON but more spectacularly in parsing JSON.

Test Environment

All these tests were run on a 21c ATP instance running on the OCI Always Free Tier. Your timings will almost certainly be better in a production environment.

Parsing JSON

Test Data

For this test, I built a JSON document containing 30,000 items (and their attributes). The resulting file is just over 10mb in size. I generated the JSON document using APEX Data Generator (available in APEX 22.1) which I recommend you check out. This is not a massive JSON document, but large enough to be meaningful. To eliminate network from the timings, I loaded the JSON document into a CLOB in a one row database table. Here is an excerpt showing 1 record from the JSON document:

{
    "ITEMS": [{
        "item_id": "36",
        "item_number": "OG8RXZ4N12",
        "description": "Winter Gloves (Green) (12 Pack)",
        "country_of_mfg": "United Kingdom",
        "channel": "ONLINE",
        "item_uom": "EA",
        "date_introduced": "27-NOV-2021",
        "status": "ACTIVE",
        "orderable": "Y"
    }]
}

Tests

I compared the performance of APEX_JSON vs two native database JSON parsing APIs, JSON_TABLE and JSON_OBJECT_T. I used the following code blocks to generate the timings. I ran each code block three times and took the average to calculate the percentage improvements.

Update 6/8/2022 - After some discussion on Twitter, I added an additional test using APEX_DATA_PARSER. I used the same JSON stored in a local table but in BLOB not a CLOB column. As confirmed by Carsten, APEX_DATA_PARSER uses JSON_TABLE behind the scenes (when available). image.png

APEX_JSON

DECLARE
  l_json_clob  CLOB;
  l_count      PLS_INTEGER;
  l_item_id    items.item_id%TYPE;
BEGIN
  SELECT json_clob INTO l_json_clob FROM test_json_parsing WHERE json_id = 5;
  -- Parse the JSON CLOB.
  apex_json.parse(l_json_clob);
  -- Count the Records Parsed.
  l_count := apex_json.get_count(p_path => 'ITEMS');
  -- Loop through parsed records, getting the item_id.
  FOR i IN 1..l_count LOOP
    l_item_id := apex_json.get_number (p_path => 'ITEMS[%d].item_id', p0 => i);
  END LOOP;
END;

JSON_TABLE

DECLARE
  CURSOR cr_json_table IS
    SELECT jt.*
    FROM   test_json_parsing tjp
    ,      JSON_TABLE(tjp.json_clob, '$.ITEMS[*]'
             COLUMNS (item_id         NUMBER         PATH '$.item_id',
                      item_number     VARCHAR2(50)   PATH '$.item_number',
                      description     VARCHAR2(100)  PATH '$.description',
                      country_of_mfg  VARCHAR2(100)  PATH '$.country_of_mfg',
                      channel         VARCHAR2(20)   PATH '$.channel',
                      item_uom        VARCHAR2(10)   PATH '$.item_uom',
                      date_introduced VARCHAR2(12)   PATH '$.date_introduced',
                      status          VARCHAR2(10)   PATH '$.status',
                      orderable       VARCHAR2(1)    PATH '$.orderable')) jt
    WHERE tjp.json_id = 5;
  l_count      PLS_INTEGER := 0;
  l_item_id    items.item_id%TYPE;
BEGIN
  -- Open the cursor which will use JSON_TABLE to Parse the CLOB.
  FOR r_rec IN cr_json_table LOOP
    l_item_id := r_rec.item_id;
    l_count   := l_count + 1;
  END LOOP;
END;

APEX_JSON_T

DECLARE
  l_items_object  JSON_OBJECT_T;
  lt_items        JSON_ARRAY_T;
  lr_item_rec     JSON_OBJECT_T;
  l_json_clob     CLOB;
  l_count         PLS_INTEGER := 0;
  l_item_id       items.item_id%TYPE;
BEGIN
  -- Get the CLOB.
  SELECT json_clob INTO l_json_clob FROM test_json_parsing WHERE json_id = 5;
  -- Parse the JSON CLOB.
  l_items_object := JSON_OBJECT_T.PARSE(l_json_clob);
  -- Get the ITEMS Array.
  lt_items       := l_items_object.get_Array('ITEMS');
  -- Get the Record Count.
  l_count        := lt_items.get_size;
  -- Loop through the items and get the item_id for each.
  FOR i IN 0..l_count -1 LOOP
    lr_item_rec := JSON_OBJECT_T(lt_items.get(i));
    l_item_id   := lr_item_rec.get_String('item_id');
  END LOOP;
END;

APEX_DATA_PARSER

DECLARE
  CURSOR cr_items IS
    SELECT col001  status
    ,      col002  channel
    ,      TO_NUMBER(col003)  item_id
    ,      col004  item_uom
    ,      col005  orderable
    ,      col006  description
    ,      col007  item_number
    ,      col008  country_of_mfg
    ,      col009  date_introduced
    FROM   apex_data_parser.parse
            (p_content           => (SELECT json_blob FROM test_json_parsing WHERE json_id = 5),
             p_file_name         => 'test.json',
             p_row_selector      => 'ITEMS',
             p_detect_data_types => 'N');
  l_count      PLS_INTEGER := 0;
  l_item_id    items.item_id%TYPE;
BEGIN
  -- Loop through parsed records, getting the item_id.
  FOR r_rec IN cr_items LOOP
    l_item_id := r_rec.item_id;
    l_count   := l_count + 1;
  END LOOP;
END;

Timings

There is not much I can add here, the timings say it all. Native database JSON parsing offers a massive performance improvement over APEX_JSON. image.png

Building JSON

Test Data

I took the JSON document used in the first test (with 30,000 records) and loaded it into a table called ITEMS.

Tests

The goal of this test is to generate a JSON document from the ITEMS table. The JSON file will have the same structure and content as the original test JSON. I compared the performance of APEX_JSON using a cursor vs APEX_JSON in a LOOP vs the native database JSON APIs JSON_TABLE and JSON_OBJECT_T. I used the following code blocks to generate the timings. I ran each code block three times and took the average to calculate the percentage improvements.

Generate JSON using APEX_JSON in Loop

DECLARE
  CURSOR cr_items IS
    SELECT *
    FROM   items;
    l_json_clob  CLOB;
BEGIN
  -- Initialize JSON
  apex_json.initialize_clob_output (p_indent => 0);
  apex_json.open_object; -- {
  apex_json.open_array('ITEMS'); -- [ ITEMS
  FOR r_item IN cr_items LOOP
    apex_json.open_object; -- {
    apex_json.write('item_id', r_item.item_id);
    apex_json.write('item_number', r_item.item_number);
    apex_json.write('description', r_item.description);
    apex_json.write('country_of_mfg', r_item.country_of_mfg);
    apex_json.write('channel', r_item.channel);
    apex_json.write('item_uom', r_item.item_uom);
    apex_json.write('date_introduced', r_item.date_introduced);
    apex_json.write('status', r_item.status);
    apex_json.write('orderable', r_item.orderable);
    apex_json.close_object; -- }
  END LOOP;
  apex_json.close_array; -- ] ITEMS
  -- Close out JSON and return CLOB.
  apex_json.close_object; -- }
  l_json_clob := apex_json.get_clob_output;
  apex_json.free_output;
END;

Generate JSON using APEX_JSON with Cursor

DECLARE
  crsr         sys_refcursor;
  l_json_clob  CLOB;
BEGIN
  -- Initialize JSON
  apex_json.initialize_clob_output (p_indent => 0);
  apex_json.open_object; -- {
  -- Open Cursor and Pass results to APEX_JSON.
  OPEN crsr FOR
    SELECT * FROM items;
  apex_json.write('ITEMS', crsr);
  -- Close out JSON and return CLOB.
  apex_json.close_object; -- }
  l_json_clob := apex_json.get_clob_output;
  apex_json.free_output;
END;

Generate JSON using JSON_OBJECT_T

DECLARE
  CURSOR cr_items IS
    SELECT * FROM items;
  l_items_obj  json_object_t := json_object_t();
  lr_item_rec  json_object_t := json_object_t();
  lt_items     json_array_t  := json_array_t ();
  l_json_clob  CLOB;
BEGIN
  -- Loop through items adding them to array.
  FOR r_item IN cr_items LOOP
    lr_item_rec.PUT('item_id', r_item.item_id);
    lr_item_rec.PUT('item_number', r_item.item_number);
    lr_item_rec.PUT('description', r_item.description);
    lr_item_rec.PUT('country_of_mfg', r_item.country_of_mfg);
    lr_item_rec.PUT('channel', r_item.channel);
    lr_item_rec.PUT('item_uom', r_item.item_uom);
    lr_item_rec.PUT('date_introduced', r_item.date_introduced);
    lr_item_rec.PUT('status', r_item.status);
    lr_item_rec.PUT('orderable', r_item.orderable);
    lt_items.APPEND (lr_item_rec);
  END LOOP;
  l_items_obj.PUT ('ITEMS', lt_items);
  l_json_clob := l_items_obj.to_clob;
END;

Generate JSON using JSON_OBJECT

DECLARE
  l_json_clob  CLOB;
BEGIN
  l_start_ts := SYSTIMESTAMP;
  SELECT JSON_OBJECT (KEY 'ITEMS' VALUE (
    SELECT JSON_ARRAYAGG(JSON_OBJECT (*) RETURNING CLOB)
    FROM   ITEMS) RETURNING CLOB
  )  INTO l_json_clob
  FROM DUAL;
END;

Timings

Another win for native database JSON functionality. Although, if you have to build your JSON using PL/SQL and a loop then the timings are much closer. image.png I was somewhat surprised that with APEX_JSON, it was faster to build the JSON in a loop rather than using the cursor approach.

Conclusion

If you are on 12c or higher of the database, you should consider switching to use native JSON parsing as soon as you can. Since 12c, Oracle has enhanced native JSON capabilities. They are much more robust and feature rich from 19c onward. If you are on 19c or higher then make the switch from APEX_JSON to native JSON today!
